Description
Wet, dry and chemical from one surface-mounted station
AA131C adds a second quick-connect outlet to the AA131 surface mount so an operator has hot water and a metered chemical or disinfectant line at the same inlet. Everything mounts to the face of the wall on one plate — ideal where in-wall boxes aren’t possible or where a facility is being converted to an Aqua-Air system after construction.
What’s included
| Part # | Item | Qty |
|---|---|---|
| PA138R | Vacuum inlet valve and cover, white | 1 |
| PA181 | Wall switch, white | 1 |
| PA086 | Square muffler, white | 1 |
| PA088 | 90° short socket elbow and pipe caps for 2″ vacuum pipe | 1 |
| PA132 | Mounting plate, 2×3 | 1 |
| PAF04 | 1/8″ female quick connect outlets with brass fittings (water and chemical) | 2 |
| BR506 | 1/2″ × 3/8″ barb PEX swivel adapter | 2 |
| — | Section of 2″ white vacuum pipe, ABS plate, solution line and stainless hardware | 1 |
Where it’s used
- Kennels, veterinary clinics and groomers retrofitting existing buildings
- Car washes and detail bays with block or steel walls
- Restaurants, food processing and commercial kitchens
- Pairs with the AA035 Dema injector for metered chemical
Installation
Surface mount — no wall cavity needed. Pipe connects at the back through the short 90° elbow and pipe caps; the built-in muffler quiets the inlet. Mounts on the 2×3 plate with the included hardware; water and chemical each connect via a 1/2″ × 3/8″ PEX swivel adapter. Replacement inlet valve/cover: PA138R. Replacement quick connect: PAF04.
